HT-22 is an electric led touch thermostat which is used for MAX 3680W floor heating or low voltage water heating application. It uses Tuya Zigbee 3.0 module for the cloud communication and App control. In order to have App operation,a Zigbee gate way is needed to have router connectivity, it will only need to take 2 steps to connect the thermostat. The App supports Smart Functionalities such as timer, schedule, temperature calibration, other smart events and so on.. |
Product | Zigbee 3.0 Smart Wireless Floor Heating Thermostat |
Item Number | HT-22 |
Display | LED |
Thermostat Dimension | 86*86*15 |
Communication | Zigbee 3.0, MQTT |
Material | Anti-flame ABS+PCS(ROHS certificated) |
Power Input | 230VAC,50/60HZ |
Load Current | 16A |
Set Temp Range | 5~35℃ |
Display Temp | 0~99℃ |
Ambient Temp | 0~50℃ |
Floor Temp | 0~80℃ |
Relative Humidity | 85% |
Sensor Type | NTC 3950 10K |
Accuracy | ± 1℃ |
Modes | Manual (permanent hold)/schedule/eco |
External Sensor | Yes (floor sensor) |
Floor Protection | yes |
Over Heat Protection | yes |
Programmable/Schedule | yes |
Interaction Method | Touch panel |
Language | English |
App | Tuya Smart, Smart Life |
Certification | CE (RED/ECM/LVD) ,Rohs |
OEM levels | 1. Customized logo and package 2. Customized software (change to customer's user interface and control logic) 3. Customized hardware(change the PCB and schematic based on the request) |
Q1: Are you a manufacturer or trading company?
We are professional OEM/ODM thermostat manufacturer since 2003 with 8000sqm factory.
Q2: What is your MOQ for batch order?
50 PCS
Q3: What is your stand lead time?
Samples : 3-5 workding days, Batch: 30-40 days
Q4: What certification do you have for your products?
CE/ROHS, FCC,UKCA, REACH(according to request)
Q5: What is your product warranty ?
1 year
Q6: How is the logo print and customized package?
We accept normally 1 color logo print, and customized CMYK printed box.
Q7: Do you have free spares for each order?
We don't have free spares but have free reparing or replacement policy , boldly to save qualify rate is 99.5%.
Q8: What is your advantage?
We have the largest manufacturing plant, full manufacturing lines, intact QC/QA systems, concentrated product OEM&ODM service
Q9: What is your main market?
Whole Europe/ME/ Asia/Latin America/ US /Canada
For more questions, please drop an email to [email protected]
