| Item Number | CH7300 |
| Display | LCD |
| Thermostat Dimension | 140*96*29.5 |
| Material | ABS+PCS(ROHS certificated) |
| Power Input | 24VAC |
| Set Temp Range | 5~35℃ |
| Ambient Temp | 0~50℃ |
| Floor Temp | 0~80℃ |
| Relative Humidity | 85% |
| Sensor Type | NTC 10K |
| WiFi | 2.4Ghz 802.11 b/g (default) |
| Terminals | R,RC,C,Y,Y2,O/BW/E,W2,G |
| Accuracy | ± 1℃ |
| Modes | Manual (permanent hold)/schedule |
| External Sensor | not supported |
| Application System | Single stage, two stages Heat Pumps, Conventional HVAC , Air Conditioners |
| Interaction Method | Press button |
| Tempearture format | Celcius, Fahrenheit |
| Certification | UL(according to request), FCC, Energy Star （According to request) |
| OEM levels | 1. Customized logo and package 2. Customized software (change to customer's user interface and control logic) 3. Customized hardware(change the PCB and schematic based on the request) |
